Posted on July 19, 2021 by Jean-Luc Aufranc (CNXSoft) - 10 Comments on AMD
Athlon 300U powered AM02 Mini PC goes for $240 and up
AMD Athlon 300U powered AM02 Mini PC goes for $240 and up

It’s not that easy to find a relatively low-cost AMD mini PC, and there
are more choices on Intel’s side.  Most models around $250-$300 are
barebone without memory or storage, but AM02 mini PC may be an interesting
option as the AMD Athlon 300U powered computer sells for about $240 plus
shipping with 8GB RAM and a 128GB SSD, which looks to be an even better
option than the Maxtang MTN-FP50 mini PC we reported on last June.

All AM02 models ship with Windows 10 by default, but you may be able to ask
the seller to install Linux instead (TBC), and support up to 16GB RAM and
1TB SSD. Note that the seller apparently made a mistake with the 16GB/256GB
model, as it is sold for just $232.89, instead of $332.89. It might still be
worth a try 🙂

	AM02 specifications:

SoC – AMD Athlon 300U dual-core/quad-thread processor @ 2.4GHz / 3.3
GHz (Turbo Boost) with 4MB L3 cache, 3-core Radeon Vega 3 GPU;  TDP: 15W;
process: 14nm
System Memory – 8GB or 16GB dual-channel DDR4 RAM; upgradeable to 32GB
max
Storage – 128GB, 256GB, 512GB, or 1TB M.2 2280 SSD; the socket
supports NVMe and SATA, but the company does not say what type of SSD is
preinstalled in the mini PC
Video Output – HDMI 2.0 port up to 4Kp60, DisplayPort up to 4Kp60
Audio – 3.5mm headphone jack
Connectivity



Gigabit Ethernet RJ45 port via RTL8168 Ethernet controller; Wake-on
-LAN (WoL) support

Intel 3165 module for dual-band WiFi 5 and Bluetooth 4.2, but the

module can also be upgraded for WiFI 6, Bluetooth 5.0 support
USB – 3x USB 3.0 port, 1x USB 2.0 port, 1x USB 2.0 Type-C port
Misc – Power button and LED
Power Supply – 12V/6A via DC jack
Dimensions – 123.5 x 123.5 x 40 mm


AMD Athlon 300U mini PC

AM02 AMD Athlon 300U mini PC ships with a charger for US, EU,  UK, or AU as
requested at the time of order, an HDMI cable, a wall-mount bracket, and a
user manual in English.

As mentioned in the introduction, the mini PC comes pre-installed with
Windows 10 (I have the feeling that’s an unlicensed version), and it
appears the company may install Linux on request, although it’s not 100%
explicit, as they just say “We will send pre-installed WIN10 if without
special requirements“.
