Anneal:
The process of altering the structure of metal so as to relieve it's working
stresses and increase it's ductivity.
Anvil:
A metallic part of the primer. The blow from the firing
pin crushes the priming mixture against the anvil causing ignition.
TOP
Ball:
In military nomenclature this term refers to the bullet.
Ball Powder:
This is a trade name for a double-base smokeless powder developed by Olin
Industries. The grains have a spherical, or flattened spherical shape.
Ballistics:
The science of projectiles in motion.
Ballistic Coefficient:
Ratio of the sectional density of a bullet to its
coefficient form. Represents the projectiles ability to overcome air resistance
in flight.
Battery Cup:
A type of primer used in shotshells which makes use
of an outside cup to support it in the case.
Bearing Surface:
That portion of the bullet surface which bears on, or touches, the
bore.
Bell:
To open the mouth of a case slightly in order to seat a bullet more easily.
Also used in reference to a rifle barrel which is worn at the muzzle (belled
muzzle).
Belted:
A band which is formed into the head of some cases (magnum type) to strengthen
the case and headspace of the cartridge.
Berdan:
A common European priming system which makes use of an
anvil formed in the case itself.
Boattail:
A bullet design having a tapered base.
Bore:
The inside diameter of a barrel before the rifling is cut.
Boxer Primer:
A type of primer used in all American rifle and pistol ammunition and featuring
a self contained anvil. It is fitted in the
primer pocket in the head of
centerfire cartridge cases.
Bullet:
That portion of the cartridge which becomes a projectile when in flight.
Burning Rate:
A term which is used to describe the rapidity with which a given powder will
burn. The term itself is a relative one based on a comparison with other
powders.
TOP
Caliber:
The approximate diameter of a bullet or bore, expressed
in decimals of an inch in English. In Europe, where the metric system is
used, this measurement is expressed in millimeter.
Cannelure:
A groove (or grooves) cut around the circumference of a bullet. These grooves,
usually one to a bullet, provide the best means of securely crimping the
case mouth into the bullet.
Case:
The metal, plastic or paper container which holds all of the components of
a round of ammunition.
Case Neck Brush:
The metal or nylon brush and handle used to clean the inside of case necks.
Case Trimmer:
A device used to remove excess material from a case mouth. Metallic cases
stretch after extensive reloading and firing because the brass flows forward.
These cases must be trimmed back.
Case Trimmer Pilot:
The pilot guides the cutting portion of the case trimmer by fitting inside
the neck of the case to be trimmed.
Cast Bullet:
Bullets for centerfire rifle or pistol which are cast
from lead alloy. Muzzleloading projectiles and shotgun slugs are cast in
pure lead.
Centerfire:
Refers to a cartridge having a centrally located primer
in it's base.
Chamber:
The part of the bore at the breech which is formed to
accept and support the loaded cartridge.
Chamfer:
To ream a taper on the inside of a case mouth.
Charge:
The amount of powder used in the case at each loading. Also refers to the
amount of shot used in a shotshell.
Choke:
A constriction at the muzzle of a shotgun barrel designed to control the
spreading of shot.
Chronograph:
An instrument used to measure the velocity of a
projectile.
Compressed Charge:
A charge of powder which so nearly fills the case that it is compressed when
the bullet is seated.
Components:
Any of the various parts which go into the making of a cartridge.
Corrosion:
The eating away of the bore by rust or chemical action.
Crimp:
The bending inward of the case mouth to grip the bullet. With shotshells
the term applies to the closure at the case mouth.
Crimped Primer:
A forcing inward of the brass around the top of the primer
pocket. This is frequently found on military cartridges and is done to
prevent set-back of primers. The crimp must be removed before repriming the
case.
TOP
Deburring Tool:
The deburring tool removes burs from the inside and outside of any newly
trimmed case mouths
Decap:
To deprime a case by removing the spent primer from
the primer pocket, most often accomplished by the decapping
pin in a die during the resizing operation of reloading.
Die:
A tool, in handloading, that reforms cartridge cases and seats bullets; or,
in bullet manufacture, a tool that swages bullets or cores, extrudes lead
wire or draws jackets.
Dram Equivalent:
Term used to indicate the approximate velocity of a shot
charge by comparison.
Drift:
Deviation of a projectile from the line of departure due to its rotational
spin or the force of wind.
Drop:
The distance a projectile falls, calculated from the line of departure.
Double Base Powder:
Smokeless powder made with nitroglycerine and nitrocellulose base.
Duplex Load:
The use of two different powders in loading the same cartridge.
TOP
Energy:
A projectile's capacity for doing work at a given range, expressed in
foot-pounds.
Erosion:
The wearing away of the bore due to friction and/or gas
cutting.
TOP
Fireform:
Reforming or changing the shape of a cartridge case by firing it in a
chamber of a desired shape.
Flash Hole:
A hole leading from the primer pocket to the inside
of a case.
Foot-Pound:
A unit of kinetic energy equal to the effort required to raise one pound
of weight; to put a height of one foot, against the normal pull of gravity.
Freebore:
The distance in the barrel, if any, which the bullet travels before it contacts
the rifling. Some barrels are purposely relieved to allow the bullet considerable
free movement before it strikes the rifling.
TOP
Gas Checks:
A gliding metal cup which is used to protect the base of a cast lead alloy
bullet from the effects of burning powder gases.
Gliding Metal:
A copper-zinc alloy used for bullet jackets and gas checks.
Grain:
A unit of weight measure. 437.5 grains equal one ounce; 7000 grains equal
one pound.
TOP
Hangfire:
Delayed ignition.
Headspace:
The distance from the breech face to the part of the
chamber which acts as a stop and prevents the cartridge
from moving forward. Also applies to the cartridge case.
Heel:
The outer edge of the bullet base.
Hollow Point:
A bullet design which features an axial hole at the point. The purpose of
the hole is to aid expansion on impact.
TOP
Ignition:
The action of setting the powder charge on fire.
IMR:
Abbreviation for "Improved Military Rifle".
TOP
Jacket:
The covering or "skin" of a bullet.
TOP
Keyhole:
The imprint of a bullet which struck sideways on target rather than point
first.
TOP
Lands:
The raised portion of the rifling.
Line of Sight:
An imaginary straight line from the eye, through the sights, to the point
of aim.
Loading Density:
Ratio of the volume of the powder charge to the volume
of the case. The higher the better in terms of accuracy.
Lube Dent:
A dent in the cartridge case caused by using too much lubricant when
resizing.
Lube Pad:
A pad, impregnated with lubricant, on which cases are rolled before
resizing.
Lubricant:
Case sizing lubricant is used to reduce friction between the case and die
during the resizing operation in reloading.
TOP
Mecuric Primer:
A primer in which the priming material contains mercury.
Metal Case (MC):
A type of bullet which, except for a small opening at the base, is completely
encased in a jacket.
Mid-Range Trajectory:
Refers to the distance the bullet rises above the line of sight. Mid-range
trajectory is calculated halfway between the muzzle and the target.
Minute-of-Angle:
A unit of angular deviation equal to 1/60th of a degree. For practical purposes,
it is usually approximated as equal to one inch at 100 yards.
Misfire:
The failure of a cartridge to fire after the primer
was struck.
Muzzle:
The front end of the barrel.
Muzzle Energy:
See "Energy"
TOP
Neck:
The upper portion of a cartridge case that grips the bullet.
Neck-Size:
To resize only the neck portion of a case.
Non-Corrosive:
Usually refers to primers having a priming mixture which is free of corrosive
compounds. Modern primers are non-corrosive.
TOP
Ogive:
Refers to the nose shape of the bullet. The radius of the curve of a bullet
nose.
TOP
Powder:
The propellant used in most firearms. It produces a large volume of gas when
ignited. There are two basic types; smokeless and black powder.
Powder Funnel:
A helpful accessory that facilitates transfer of powder from a scale pan
or measure to a cartridge case.
Powder Measure:
An adjustable volumetric measure that meters out uniform charges of powder.
Powder Scale:
A device to weigh charges of powder. A beam scale is a scale where markers,
called "poise", are moved along a weight graduated beam, as the pan is filled
with powder, until the balance point is reached. An electronic device used
to measure the weight of powder in grains or grams.
Pressure:
The force exerted by a burning charge of a powder in
the chamber of a firearm. Expressed normally in pounds
per square inch.
Primer:
A small metal cap containing the detonating mixture which is used to ignite
the propellant charge.
Primer Pocket:
The cavity in the base of a cartridge which receive and supports the
primer.
TOP
Ram:
The main shaft of a metallic cartridge reloading tool.
Resizing Die:
The reloading die that resizes fired cartridge cases and removes spent primers
by means of a decapping pin.
Round:
A military term meaning one single cartridge.
Round Nose (RN):
A bullet design which features a rounded nose.
TOP
SAMMI:
An abbreviation for "Sporting Arms and Ammunition Manufacturers Institute".
Seating Depth:
The depth to which a bullet is seated below the case mouth.
Seating Die:
The reloading die that presses the bullet into the neck of the cartridge
case, crimping the case if so desired.
Sectional Density:
A bullets weight, in pounds, divided by the square of it's diameter in
inches.
Shell Holder:
This is attached to the top of the ram and holds the heads of the cartridge
cases as they are moved up and down, into and out of the die.
Swage:
To pressure-form by forcing through or into a die.
TOP
Throat:
That area of the bore immediately ahead of the
chamber.
Trajectory:
The path of a projectile in flight.
Trim-to-Length:
The length a cartridge case should be trimmed to after it has stretched past
it's maximum case length.
Turret Press:
A reloading press with a rotatable multi station turret top for positioning
dies and powder measure in their appropriate sequence.
TOP
Velocity:
The speed at which a projectile travels. Usually measured in feet per second
at a given range.
Vernier Caliper:
A slide-type graduated instrument used to measure overall cartridge and case
lengths precisely.
TOP
Wad Cutter (WC):
A bullet design which features a sharp shoulder. Designed to cut a clean
round hole in a paper target.
Web:
That portion of a cartridge case between the bottom of the
primer pocket and the interior of the case.
Work-Harden:
Brass becomes harder as it is worked. See "Anneal".
TOP
X-Ring:
Center of a target. Bulls-eye.
TOP
Yaw:
The action of a projectile spinning erratically around it's own axis.
TOP
Zero:
The ranges at which a firearm will hit the point of aim.
TOP
© www.reloadbench.com 1999 - 2005 All Rights Reserved
Help support The Reload Bench by shopping our sponsors...
