systemd for Administrators, Part VII Here's yet another installment of my ongoing series on systemd for Administrators:
The Blame Game Fedora 15[1] is the first Fedora release to sport systemd. Our primary goal for F15 was to get everything integrated and working well. One focus for Fedora 16 will be to further polish and speed up what we have in the distribution now. To prepare for this cycle we have implemented a few tools (which are already available in F15), which can help us pinpoint where exactly the biggest problems in our boot-up remain. With this blog story I hope to shed some light on how to figure out what to blame for your slow boot-up, and what to do about it. We want to allow you to put the blame where the blame belongs: on the system component responsible. The first utility is a very simple one: systemd will automatically write a log message with the time it needed to syslog/kmsg when it finished booting up. systemd[1]: Startup finished in 2s 65ms 924us (kernel) + 2s 828ms 195us (initrd) + 11s 900ms 471us (userspace) = 16s 794ms 590us. And here's how you read this: 2s have been spent for kernel initialization, until the time where the initial RAM disk (initrd, i.e. dracut) was started. A bit less than 3s have then been spent in the initrd. Finally, a bit less than 12s have been spent after the actual system init daemon (systemd) has been invoked by the initrd to bring up userspace. Summing this up the time that passed since the boot loader jumped into the kernel code until systemd was finished doing everything it needed to do at boot was a bit less than 17s. This number is nice and simple to understand -- and also easy to misunderstand: it does not include the time that is spent initializing your GNOME session, as that is outside of the scope of the init system. Also, in many cases this is just where systemd finished doing everything it needed to do. Very likely some daemons are still busy doing whatever they need to do to finish startup when this time is elapsed. Hence: while the time logged here is a good indication on the general boot speed, it is not the time the user might feel the boot actually takes. Also, it is a pretty superficial value: it gives no insight which system component systemd was waiting for all the time. To break this up, we introduced the tool systemd-analyze blame: $ systemd-analyze blame 6207ms udev-settle.service 5228ms cryptsetup@luks\x2d9899b85d\x2df790\x2d4d2a\x2da650\x2d8b7d2fb92cc3.service 735ms NetworkManager.service 642ms avahi-daemon.service 600ms abrtd.service 517ms rtkit-daemon.service 478ms fedora-storage-init.service 396ms dbus.service 390ms rpcidmapd.service 346ms systemd-tmpfiles-setup.service 322ms fedora-sysinit-unhack.service 316ms cups.service 310ms console-kit-log-system-start.service 309ms libvirtd.service 303ms rpcbind.service 298ms ksmtuned.service 288ms lvm2-monitor.service 281ms rpcgssd.service 277ms sshd.service 276ms livesys.service 267ms iscsid.service 236ms mdmonitor.service 234ms nfslock.service 223ms ksm.service 218ms mcelog.service ... This tool lists which systemd unit needed how much time to finish initialization at boot, the worst offenders listed first. What we can see here is that on this boot two services required more than 1s of boot time: udev-settle.service and cryptsetup@luks\x2d9899b85d\x2df790\x2d4d2a\x2da650\x2d8b7d2fb92cc3.service . This tool's output is easily misunderstood as well, it does not shed any light on why the services in question actually need this much time, it just determines that they did. Also note that the times listed here might be spent "in parallel", i.e. two services might be initializing at the same time and thus the time spent to initialize them both is much less than the sum of both individual times combined. Let's have a closer look at the worst offender on this boot: a service by the name of udev-settle.service. So why does it take that much time to initialize, and what can we do about it? This service actually does very little: it just waits for the device probing being done by udev to finish and then exits. Device probing can be slow. In this instance for example, the reason for the device probing to take more than 6s is the 3G modem built into the machine, which when not having an inserted SIM card takes this long to respond to software probe requests. The software probing is part of the logic that makes ModemManager work and enables NetworkManager to offer easy 3G setup. An obvious reflex might now be to blame ModemManager for having such a slow prober. But that's actually ill-directed: hardware probing quite frequently is this slow, and in the case of ModemManager it's a simple fact that the 3G hardware takes this long. It is an essential requirement for a proper hardware probing solution that individual probers can take this much time to finish probing. The actual culprit is something else: the fact that we actually wait for the probing, in other words: that udev-settle.service is part of our boot process. So, why is udev-settle.service part of our boot process? Well, it actually doesn't need to be. It is pulled in by the storage setup logic of Fedora: to be precise, by the LVM, RAID and Multipath setup script. These storage services have not been implemented in the way hardware detection and probing work today: they expect to be initialized at a point in time where "all devices have been probed", so that they can simply iterate through the list of available disks and do their work on it. However, on modern machinery this is not how things actually work: hardware can come and hardware can go all the time, during boot and during runtime. For some technologies it is not even possible to know when the device enumeration is complete (example: USB, or iSCSI), thus waiting for all storage devices to show up and be probed must necessarily include a fixed delay when it is assumed that all devices that can show up have shown up, and got probed. In this case all this shows very negatively in the boot time: the storage scripts force us to delay bootup until all potential devices have shown up and all devices that did got probed -- and all that even though we don't actually need most devices for anything. In particular since this machine actually does not make use of LVM, RAID or Multipath![2] Knowing what we know now we can go and disable udev-settle.service for the next boots: since neither LVM, RAID nor Multipath is used we can mask the services in question and thus speed up our boot a little: # ln -s /dev/null /etc/systemd/system/udev-settle.service # ln -s /dev/null /etc/systemd/system/fedora-wait-storage.service # ln -s /dev/null /etc/systemd/system/fedora-storage-init.service # systemctl daemon-reload After restarting we can measure that the boot is now about 1s faster. Why just 1s? Well, the second worst offender is cryptsetup here: the machine in question has an encrypted /home directory. For testing purposes I have stored the passphrase in a file on disk, so that the boot-up is not delayed because I as the user am a slow typer. The cryptsetup tool unfortunately still takes more han 5s to set up the encrypted partition. Being lazy instead of trying to fix cryptsetup[3] we'll just tape over it here [4]: systemd will normally wait for all file systems not marked with the noauto option in /etc/fstab to show up, to be fscked and to be mounted before proceeding bootup and starting the usual system services. In the case of /home (unlike for example /var) we know that it is needed only very late (i.e. when the user actually logs in). An easy fix is hence to make the mount point available already during boot, but not actually wait until cryptsetup, fsck and mount finished running for it. You ask how we can make a mount point available before actually mounting the file system behind it? Well, systemd possesses magic powers, in form of the comment=systemd.automount mount option in /etc/fstab. If you specify it, systemd will create an automount point at /home and when at the time of the first access to the file system it still isn't backed by a proper file system systemd will wait for the device, fsck and mount it. And here's the result with this change to /etc/fstab made: systemd[1]: Startup finished in 2s 47ms 112us (kernel) + 2s 663ms 942us (initrd) + 5s 540ms 522us (userspace) = 10s 251ms 576us. Nice! With a few fixes we took almost 7s off our boot-time. And these two changes are only fixes for the two most superficial problems. With a bit of love and detail work there's a lot of additional room for improvements. In fact, on a different machine, a more than two year old X300 laptop (which even back then wasn't the fastest machine on earth) and a bit of decrufting we have boot times of around 4s (total) now, with a resonably complete GNOME system. And there's still a lot of room in it. systemd-analyze blame is a nice and simple tool for tracking down slow services. However, it suffers by a big problem: it does not visualize how the parallel execution of the services actually diminishes the price one pays for slow starting services. For that we have prepared systemd-analyize plot for you. Use it like this: $ systemd-analyze plot > plot.svg $ eog plot.svg It creates pretty graphs, showing the time services spent to start up in relation to the other services. It currently doesn't visualize explicitly which services wait for which ones, but with a bit of guess work this is easily seen nonetheless. To see the effect of our two little optimizations here are two graphs generated with systemd-analyze plot, the first before and the other after our change:
|
