GPIO pins of ESP32 – LED Blinking example

In this tutorial, we will learn how to use GPIO pins of the ESP32 devkit with
LED blinking examples using Arduino IDE. Whenever any beginner starts learning
about any microcontroller-based development board, Experts always recommend
beginners to start with an LED blinking example which is also known as a light
emitting diode. LED blinking examples use general-purpose input output pins to
turn on and turn off the LED. By learning how to control GPIO pins, you will be
able to use GPIO pins of ESP32 board for other applications like LCD interfacing,
keypad interfacing, and other embedded system projects.


ESP32 LED Blinking Tutorial Prerequisites


Let’s start with the basic introduction of general-purpose input-output pins of
the ESP32 Devkit. You can use any ESP32 development board you want until it has
an ESP-WROOM-32 chip on it. Also, the concepts used in this article will remain
applicable to other types of ESP32 boards.  For more features of this board, you
can go through this tutorial:

    Introduction to the ESP32 development board

We will be using Arduino IDE to program ESP32. So if you don’t know how to
install a library of this IOT board you can check this tutorial:

    How to install ESP32 in Arduino IDE


ESP32 GPIO Pins


In the market, various ESP32 dev kits are available, and the one used in this
tutorial has 36 GPIO pins, although not all of them can be utilized as digital
output pins. Out of a total of 30 pins, 24 pins can function as both digital
input and output, while the remaining six pins (GPIO34, GPIO35, GPIO36, GPIO37,
GPIO38, GPIO39) can only serve as digital input pins. Nonetheless, the 24 pins
available for digital output are sufficient to power LED, relay, seven-segment
displays, liquid crystal display, and other actuators. Therefore, any of the
thirty pins can be utilized for this purpose.

Note: GPIO6 to GPIO 11 are not exposed to pinout of ESP32 dev kit which we are
using in this tutorial. Because these pins are internally connected to the
integrated SPI flash on the ESP-WROOM-32 chip.

Do you want to learn the difference between a sensor and an actuator? Check here.
For more information about the GPIO pins of the ESP32 development board, check
this article:

    ESP32 pinout and details of each pin

Now that I believed you have already installed ESP32 in Arduino IDE You have
also gone through the article on ESP32 pinout. Now let’s see how to blink an LED
using ESP32 and Arduino IDE.


ESP32 pin mapping


LED Blinking Example Using ESP32


As I mentioned earlier in ESP32, we have can use 30 pins as a digital output
pin. Now let’s select one pin and used it to turn on and turn off LED with some
delay.

In this example, we will control an LED with GPIO22 of ESP32. That means we will
learn to use GPIO pins as digital output pins. We connect an LED to GPIO22
through a current limiting resistor of 220 ohms. This ESP32 LED blinking example
works as mentioned below:

RED LED Turns on for one second which means GPIO22 goes to an active high state
In the next step, the LED turns off for one second which means GPIO22 goes
to an active low state
The above two steps keep repeating as shown below:


LED blinking ESP32 example in Arduino IDE



LED Blinking Connection Diagram


As you can in the above pinout diagram of ESP32, we have a total of 36 GPIO pins,
but we will be using GPIO22 as a digital output pin. On different boards, these
pins can be located at different locations. Therefore, you need to check its
datasheet before using pin number in programming which I will explain in the
programming part of this article.

Now check the schematic and make it on your breadboard as shown below:
LED blinking ESP32


Now make the circuit connection according to the above circuit diagram on the
bread board.

Connect GPIO22 with the anode or positive pin of the LED. Positive pin is
usually round edge.
Connected other end of the LED with ground through 330 ohm resistor.
Resistor is used as a current limiting resistor.
Each pin can provide a maximum of 10mA current. So current limiting resistor
is used to limit current not crossing this limit.
If you want to use GPIO pins to drive any other device which has a higher
current requirement, you should connect a transistor in between or current
driver integrated circuit like ULN2003 relay driver circuit IC.



ESP32 GPIO Pins Arduino Functions


To write code for LED blinking using ESP32, first, you need to understand three
main functions used in Arduino IDE to control general purpose input output pins.
If you have already used Arduino IDE for Arduino or esp8266 programming, you
will be already familiar with these functions :


pinMode() : This function is used to select input output pin mode either as
a input or output. First argument to this function is pin number to which you
want to declare either as a input or output. Second argument to this function is
in which direction you want to use a digital pin. For example, if we write
pinMode(22, OUPUT) , it will declare pin number 22 as a digital output pin.
digitalWrite(pin_number, LOGIC_HIGH_LOW) : This function is used to control
digital output pin. First argument is a pin number and second value to this
function is logic state ‘HIGH’ or ‘LOW’. For example, if you write
digitalWrite(22, HIGH), it will make pin number 22 logic HIGH or 3.3 volt and
if you write digitalWrite(22, LOW), it will make digital output pin 22 LOW or
you will get zero volt at the output pin.
delay(value) : This function is used to generate delay in mili seconds. If
you want to add a delay of one second between turning on and turning off a LED,
you will use this state delay(1000).
setup( ) : In Arduino IDE, setup function is used for declaration or
initialization. A pinMode function is used for declaration of digital pins. So
it will be defined inside setup function. It will become more clear when you see
the example code at the end of this article.
Loop( ) : In Arduino IDE, loop function is like a main function in C
programming.  In c programming whenever, you want to perform certain tasks again
and again, we use those c statements inside the loop. Similarly, we use loop
function in Arduino IDE to perform certain tasks again and again.



Arduino Code


This code is used to blink an LED connected with pin number 22 with a delay of
one second.


/*F********************************************************************
*
**********************************************************************/
void
setup()
{
	pinMode( 22, OUTPUT ); // Set GPIO22 as digital output pin
}
/*F********************************************************************
*
**********************************************************************/
void
loop()
{
	digitalWrite( 22, HIGH ); // Set GPIO22 active high
	delay( 1000 );  // delay of one second
	digitalWrite( 22, LOW ); // Set GPIO22 active low
	delay( 1000 ); // delay of one second
}

The code consists of two functions: setup() and loop().

The setup() function is called once when the board is first powered on or reset.
It sets the mode of GPIO22 to an output pin.

The loop() function is called repeatedly after setup() and contains the main
logic of the program.

In loop(), the digital pin 22 is turned on (set to a HIGH state) using the
digitalWrite() function. Then a delay of 1000 milliseconds (1 second) is
introduced using the delay() function. After the delay, the pin 22 is turned off
(set to a LOW state) using digitalWrite() function again. Another delay of 1000
milliseconds is introduced. This process of turning the pin on and off is
repeated indefinitely in a loop.

digitalWrite( 22, HIGH ); // Set GPIO22 active high
delay( 1000 );  // delay of one second
digitalWrite( 22, LOW ); // Set GPIO22 active low
delay( 1000 ); // delay of one second

In summary, this code turns on and off a digital pin (GPIO22) on an Arduino
board with a delay of 1 second between each state change. This can be used for
various purposes such as blinking an LED connected to the pin, controlling a
relay, or sending signals to other devices.


ESP32 LED Blinking Demo


Now to run this example of LED blinking using ESP32, simply copy this code to
Arduino IDE and compile the code.

After compiling code, click on the upload button to upload the code to the
ESP32 devkit.

Before uploading the code, make sure you have selected the board and COM pin to
which your ESP32 board is connected.


If you do not see this board in the tools>port option, you need to install the
driver for this board, you can download and install drivers from this link.

Go to tools>Boards and select ESP32


Go to tools>Upload speed and choose 115200

Also, select Flash Frequency of 80Mhz from the tools options.

Now click on the upload button.


After that, you will see LED will be blinking with a delay of one second.

It is a getting started tutorial with ESP32. To explore more tutorials and
projects follow these guides:
